Black Powder Painted Garrison Fence 1800mm x 2400mm and 2100mm x 2400mm
1. Heavy duty Crimp top security fence in Black colour only
2.Width 2400mm x Height 1800mm Crimp top diamond shape
3.40x40x1.6mm top rail, 20x20x1.2mm Verticals
4. There are 17 vertical pickets 20x20mm with diamond crimped on top.
5. A gap in between the pickets is 110mm
6. 60x60x2mm thick post - these are 3m long each not 2.6m long as others supply.
7. Normal fence powder coated brackets
8. Security fence brackets ( powder coated )
9. Caps for 60x60 posts (powder coated )
10. Phosphate treated before powder coating (Very Important) - Not many suppliers even know about this process.
11. All panels are fully protected
Product detailed introduction
1) Our panels are made out of the thicker material top and bottom rails 40x40x1.6and 20x20x1.2 for all verticals
2) The gap in between the verticals is 110mm compared to wider gaps with others.
3) We use for all our panels galvanized material only.
4) Very important is that we phosphate wash our panels before powder coating which means a very high-quality powder coating which will long last many years compared to my competitors.
Usages:
Widely used in villas, community, gardens, schools, factories and other flower beds, lawns, industrial and mining enterprises, financial institutions, sports stadiums, convention centers, squares, roads, balconies, residential use, its flowing lines, simple and beautiful and full of rich modern residential sensual, garden Light, villas era of high-grade. Simple installation, easy maintenance, easy to clean, affordable, eliminating maintenance.
Common specification:
| Rail(mm) | Picket(mm) | Center space(mm) | Post(mm) |
| 32*32*1.2 40*40*1.2 45*45*1.2 32*32*1.0 40*40*1.0 45*45*1.0 | 16*16*1.0 19*19*1.0 25*25*1.0 16*16*0.8 19*19*0.8 25*25*0.8 | 116 124 130 116 124 130 | 50*50*1.5 60*60*2.0 75*75*2.0 |
Note: Special specification is available as your request
The main manufacture process:
Assembled:
1>Cut Shot
2>Punching Holes
3>Acid-Washing
4>Rich-Zinc Powder Coating
5>Polyester Color Powder Coating
6>Assembly
7>packing
Welded:
1>Cut Shot
2>Welded
3>Acid-Washing
4>Rich-Zinc Powder Coating
5>Polyester Color Powder Coating
6>packing
Package form: It can assemble nets piece of form, or cooperate with bolts or rivets after the packaging.
Special specifications can be produced by the customer's requirements. We also can design for you.
If you are interested in our products, pls do not hesitate to contact us.
