Australia SYDNEY welded garrison steel fencing panels

Name: Australia SYDNEY welded garrison steel fencing panels
Brand: Tubular Crimped Spear Steel Security Fence
Price: 66.66 USD

Wholesale Australia SYDNEY welded garrison steel fencing panels from china suppliers

Brand Name : Tubular Crimped Spear Steel Security Fence

Model Number : Steel Fence-1200mm-1500mm-1800mm-2100mm-2400mm

Certification : AS/NZS1163& AS/NZS4506-1998

Place of Origin : New Zealand And Australia Design

MOQ : 300

Price : 66.66$

Payment Terms : TT 30% deposit balance 70% at sight of done cargo

Supply Ability : 90001

Delivery Time : 7 days

Packaging Details : Metal Pallet With Plastic Jacket

Materials : Q235

Color : Black and Grey or other

Dimensions : 1800mm x 2400mm ,2100mm x 2400mm or Customized

Salt Spray Testing : Pass

Treatment : Powder Coated ,Hot Dipped Galvanized

Technical : Punch Pipes and Welding etc

Nick Name : Steel Fence ,Steel Tubular Fence ,Steel Spear Fence,Garrison Fence,ornamental steel fence

Upright Pipes : 25mm x 25mm x 1.20mm

Rails : 40mm x 40mm x 1.60mm

Post : 65mm x 65mm x 2.00mm x 3000mm

Popular : Powder Coated Stain Black

Apllication : Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence

Contact Now

Australia SYDNEY welded garrison steel fencing panels

Welded garrison steel fencing panels often used decoratively for domestic boundaries, using the vertical steel pales, the pickets and horizontal rails to form the fence. Horizontal top rail and bottom rail are attached to fence posts by screws, which are installed upright into the ground Evenly spaced boards are affixed vertically to the rails. Steel fencing is strong, durable and fulfil many demanding roles.

To achieve ideal electrostatic spraying polyester effect, our spraying power adopts AKZO NOBEL, which manufacturer is one of the world's top 500 enterprises.

It is regularly used around industrial units, civic amenities, schools, residence and other such applications where security is a major concern. With its Decoration function, it is popular in most countries and areas.

Australia SYDNEY welded garrison steel fencing panels

Detailed Images

Size	2400mm (L) x 2100mm (H) , 2400mm (L) x 1800mm (H) 2000mm (L) x 1500mm (H) , 2000mm (L) x 1200mm (H)
Rail	40mm x 40mm x 1.6mm/1.2mm, 38mm x 25mm x1.6mm/1.2mm 2 rails, 3 rails or 4 rails
Picket	25mm x 25mm x 1.2mm/1.0mm 19mm x 19mm x 1.0mm/0.8mm
Post	60mm x 60mm x 2.5mm/2.0mm/1.5mm 80mm x 80mm x 2.5mm/2.0mm/1.5mm
Fittings	Metal clips , bolt and nuts
Raw Material	Hot dipped galvanized tube
Surface Face	Powder coated , Popular color is black

Australia SYDNEY welded garrison steel fencing panels

Producing Process:
CAD design---Raw Material--Cutting--Fix moulding--welding---polishing---Sandblasting---Powder coated---Inspection---Packing

Garrison steel fencing panels Standard size:

1. Heavy duty Crimp top security fence in Black colour only
2.Width 2400mm x Height 2100mm Crimp top diamond shape
3.40x40x1.6mm top rail, 25x25x1.2mm Verticals
4. There are 17 vertical pockets with diamond crimped on top
5. A gap in between the pickets is 110mm
6.60x60x2mm thick post - these are 2.9m long each not 2.6m long as others supply

Advantages:
1. Our garrison fence widely used in the garden, outdoor, villa, balcony, indoor decoration, we have many items for your choice
2. We could design for your project according to your idea, or product according to your drawing directly.
3. We own certificate of the system of quality certification, we were responsible for all the products we produced.
4. Soonest delivery and good after-sale- service

Packing & Delivery

A.Panel: each panel wrapped in plastic film or bubble film, then metal or a wooden pallet.
B. Post: each piece wrapped in pearl film or bubble film, then metal or wooden pallet
C. Accessories: woven bag or carton
D. We also can pack the goods according to your requirements.

Australia SYDNEY welded garrison steel fencing panels Images
