Hot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb Wire

Product Categories
Top Fencing Co.Limited
Contact Now

Hot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb Wire

Brand Name : LNF-Temporary Construction Fence

Model Number : 4'6'8' Height and 2100mm height etc

Certification : ASTM

Place of Origin : American ,Australia ,Canadan

MOQ : 500 liner meter

Price : 8.88$ per liner meter

Payment Terms : TT30% deposit balance 70% at sight of finished products

Supply Ability : 10000 liner meters

Delivery Time : 7 work days

Packaging Details : All metal Pallets

Materials : Q235 Steel Pipes and Wire

Mesh Opening : 2"x2"/(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜"x2⅜"(60mmx60mm) 2½"x2½"(63mmx63mm)

Diameter : 10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3mm

Size : 6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on

Color : Hot dipped galvanized

Warranty : 5-15 years depand on treatment

Customized : Available

Base : 36" length x 30" width x 8"Height /914mmx762mmx203mm

Accessoires : Top Couper

Contact Now

Hot Dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb Wire

Techniques of temporary chain link fence
Excellent surface coating and protect techniques.
Fully equipped powder coating line.

Temporary Panels Characteristic:
Excellent rust resistant (fifteen years guarantee)
Rich optional color
Unique modeling
Easy to install
Environmental protection
Corrosion Form: Hot-dipped galvanized after welded, pre-galvanized tubes then Powder coating.

Specification:
ODM/OEM/Customized Services Available
Product code
panel size(mm)
Frame Pipe(mm)
Up-Right Pipe(mm)
1
6'*8',6'*10',6'*12',6*14' OR Customzied
OD1.65'' x 0.078''/0.07''/0.063''/0.047''
OD1.65''x 0.078''/0.07''/0.063''/0.047''
2
OD1.26''x0.078''/0.07''/0.063''/0.047''
OD1.26''x0.078''/0.07''/0.063''/0.047''
3
OD1.18''x0.078''/0.07''/0.063''/0.047''
OD1.18''x0.078''/0.07''/0.063''/0.047''
Chain Link
3'' * 3'' *11.5Ga or Customized
Bracket&Post
Suggest 7.5' pre-Gal post and 9.5' pre-Gal post as corner post
Galvanized Base Supporting 35.5''*16''
Hot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb WireHot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb Wire
Chain link fence panels with the bottom foot are great for immediate use. These multi-purpose panels are easy to assemble and dismantle, are self-standing on a foot piece, they are the best choice for security purpose, crowd and traffic control, construction, outdoor event, flea markets, trade shows, and many more applications. We are a direct-factory providing competitive rates at any given scale. Foot pieces allow panels to free stand. Side clamps allow fence panels to be connected to another panel.
Product Name
America market galvanized safety chain link fence for sale
Material
Low carbon steel
Surface Treatment
Hot dipped galvanized
Height*Length
6*10ft, 6*12ft, 8*10ft, etc
Frame tube
33.4mm*1.6mm thickness
Cross tube
25mm*1.5mm thickness
Mesh opening
57*57mm*2.7mm
FeeT
610*590mm
Hot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb WireHot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb WireHot dipped Galvanized Chain Link Fence Panels Height 6' Width 10' 33mm outer frame with Barb Wire
